AGGREGATION ROUTERS

With the introduction of 5G mobile networks, carrier and cloud service providers are planning to upgrade their network infrastructure to address the major growth in bandwidth driven by new innovative services and the increased number of users. Edgecore’s solution based on Broadcom StrataDNX family chipsets with Deep Buffer design, providing an open networking platform that serves a variety of use cases, including core, metro, and aggregation routers.

Key Features

Audi
Rich Partner Ecosystem
Audi
High Capacity External TCAM
Audi
Multirole Capable
Audi
Field Proven
AGR100 Series
  • 800G AGGREGATION ROUTER AS5916-54XKS 48 x 10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

    800G AGGREGATION ROUTER AS5916-54XKS 48 x 10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

  • 800G AGGREGATION ROUTER AS5916-54XM 48 x 10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

    800G AGGREGATION ROUTER AS5916-54XM 48 x 10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

  • 800G AGGREGATION ROUTER AS5916-54XL 48 x 1G/10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

    800G AGGREGATION ROUTER AS5916-54XL 48 x 1G/10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

  • 800G AGGREGATION ROUTER AS5912-54X 48 x 1G/10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

    800G AGGREGATION ROUTER AS5912-54X 48 x 1G/10G SFP+, 6 x 100G QSFP28 with Qumran MX. Carrier access / aggregation and ToR data center switch

AGR400 Series
  • 2.4T AGGREGATION ROUTER AS7946-74XKSB 64 x 10G/25G, 8/2 x 100G with Qumran 2C. High-performance 25GbE leaf router for telecom and data center applications

    2.4T AGGREGATION ROUTER AS7946-74XKSB 64 x 10G/25G, 8/2 x 100G with Qumran 2C. High-performance 25GbE leaf router for telecom and data center applications

  • 2.4T AGGREGATION ROUTER AS7946-30XB 4 x 25G, 22 x 100G, 4 x 400G Hi-PWR with Qumran 2C High-performance 100GbE spine router for telecom and data center applications

    2.4T AGGREGATION ROUTER AS7946-30XB 4 x 25G, 22 x 100G, 4 x 400G Hi-PWR with Qumran 2C High-performance 100GbE spine router for telecom and data center applications

Comparison

Product Name Switch Silicon Port Interface Switching Capacity Forwarding Rate Packet Buffer Size Operation Temperature Airflow
AGR100 Qumran MX 48 x 1G/10G SFP+
6 x 100G QSFP28
800Gbps 720 Mpps Deep Buffering
16MBytes On-Chip
6Gb DRAM-Based
0ºC~40ºC Front-to-Back
Back-to-Front
AGR110 Qumran MX 48 x 1G/10G SFP+
6 x 100G QSFP28
800Gbps 700 Mpps Deep Buffering
48Gb DRAM-Based
0ºC~40ºC Front-to-Back
AGR120 Qumran MX 48 x 1G/10G SFP+
6 x 100G QSFP28
800Gbps 700 Mpps Deep Buffering
48Gb DRAM-Based
0ºC~40ºC Front-to-Back
Back-to-Front
AGR130 Qumran MX 48 x 1G/10G SFP+
6 x 100G QSFP28
800Gbps 700 Mpps Deep Buffering
16MBytes On-Chip
8Gb DRAM-Based
0ºC~40ºC Front-to-Back
AGR400 Qumran 2C 4 x 10G/25G SFP28
18 x 100G QSFP28
4 x 100G QSFP-DD
4 x 400G QSFP-DD
2.4 Tbps 1000Mpps Deep Buffering
4GB On-Chip
0°C to 45°C Front-to-Back
AGR420 Qumran 2C 64 x 10G/25G SFP28
8 x 100G QSFP28
2 x 100G QSFP-DD
2.4 Tbps 1000Mpps Deep Buffering
4GB On-Chip
0°C to 45°C Front-to-Back
