Cloud Data Center  |  1G

  |  EPS201

348G ENTERPRISE SWITCH

EPS201

AS4630-54TE
48 x 1G RJ45, 4 x 25G, 2 x 100G ports with Trident 3.
Open network switch for data center racks or enterprise environment

Audi
100G Interfaces
Audi
25G Interfaces
Audi
Multirole Capable
Audi
Front to Back/ Back to Front Airflow
Audi
VxLAN NVGRE
Audi
Non-blocking Design

Overview

The Edgecore EPS201 is a high-performance Gigabit Ethernet Layer 3 switch featuring 54 ports; the EPS201 has 48 x 10/100/1000BASE-T ports, 4 x 25G SFP28 uplink ports, and 2 x 100G QSFP28 uplink ports. The EPS201 is ideal as a data center top-of-rack, enterprise, or campus switch, it includes redundant hot-swappable AC PSUs and port-to-power or power-to-port airflow. This open network switch is loaded with the Open Network Install Environment (ONIE), which supports the installation of compatible Network Operating System soſtware, including the open source options, plus commercial NOS offerings.

For privacy reasons YouTube needs your permission to be loaded. For more details, please see our Privacy Policy.
I Accept

Features

  • Cost-effective open networking switch for management in data center racks, or for enterprise access networks.
  • 1GbE connections to server node and storage node management ports in rack, with 25GbE uplinks to management network aggregation switches.
  • 48 x 10/100/1000BASE-T RJ-45 ports.
  • 4 x 25G SFP28 uplink ports supporting 10GbE/25GbE.
  • 2 x100G QSFP28 stacking ports (Subject to NOS implementation).
  • Support TPM 1.2 with LPC interface.
  • Options to enable UEFI Secure Boot.
  • Full line-rate L2 or L3 forwarding and switching.
  • Hot-swappable, load-sharing, redundant AC PSUs.
  • Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commerical NOS offerings.

Compatible
Software Option

  • Arrcus – ArcOS

  • BISDN Linux

  • Pica8 – PicOS

  • SONiC

Compatible
Transceivers

  • 10G SFP

  • 25G SFP28

  • 40G QSFP+
  • 100G QSFP28

Compatible
Cables

  • 10G SFP+ DAC

  • 10G SFP+ AOC

  • 25G SFP28 DAC

  • 25G SFP28 AOC

  • 40G QSFP+ DAC
  • 40G QSFP+ AOC

  • 100G QSFP28 DAC
  • 100G QSFP28 AOC
  • 100G DAC QSFP28 to SFP28 Breakout

  • 100G AOC QSFP28 to SFP28 Breakout

Downloads

EPS201 (AS4630-54TE) Safety and Regulatory Information R02

Safety and Regulatory Information  763 KB

EPS201 (AS4630-54TE) DS R04

Datasheet  1 MB

EPS201 (AS4630-54TE) Quick Start Guide R04

User Manual  1 MB
