ACCESS ROUTERS

Mobile operators are rapidly building new capacity to respond the high-bandwidth connectivity and demands for new services and subscribers with existing 3G, 4G, and future 5G infrastructures. Open network solutions are ideal for this high-volume cell site and cell site aggregation infrastructure.

Edgecore pioneered open network CSR portfolio was the first vendor to contribute open platforms to the Open Compute Project (OCP) and the Telecom Infra Project (TIP). The high-performance, deep-packet buffer of CSR series is suitable for access and aggregation applications in remote cabinet and facility-based deployments, which are inclusive of flexible combinations of 1G, 10G, 25G, 100G, and 400G network interfaces. Edgecore CSR brings the benefits of reducing operator costs, quickening the pace of innovation, and offering the ultimate choice for network operators with a vibrant ecosystem of Network Operating System (NOS) software.

Key Features

Audi
Temperature Hardened
Audi
IEEE 1588v2 PTP w/SyncE
Audi
GNSS Antenna Port Support
Audi
Time Sensitive Networking Interfaces
Audi
eCPRI Encapsulation
Audi
Low Latency Design
Audi
Supporting Hi-Powered Optics/XCVF
Audi
Compact Design
CSR Series
  • 800G CELL SITE ROUTER AS7535-28XB 24 x 1G/10G/25G, 2 x 100G, 2 x 400G with Qumran-2A. Open disaggregated cell site gateway for 5G mobile xHaul networks

    800G CELL SITE ROUTER AS7535-28XB 24 x 1G/10G/25G, 2 x 100G, 2 x 400G with Qumran-2A. Open disaggregated cell site gateway for 5G mobile xHaul networks

  • 300G CELL SITE ROUTER AS7316-26XB 16 x 10G, 8 x 25G, 2 x 100G switch ports with Qumran AX. Open design cell site gateway for mobile backhaul networks

    300G CELL SITE ROUTER AS7316-26XB 16 x 10G, 8 x 25G, 2 x 100G switch ports with Qumran AX. Open design cell site gateway for mobile backhaul networks

  • 300G CELL SITE ROUTER AS7315-27X 20 x 1G/10G, 4 x 1G/10G/25G, 3 x 100G switch ports with Qumran AX. Open cell site gateway platform for mobile backhaul networks

    300G CELL SITE ROUTER AS7315-27X 20 x 1G/10G, 4 x 1G/10G/25G, 3 x 100G switch ports with Qumran AX. Open cell site gateway platform for mobile backhaul networks

  • 300G CELL SITE ROUTER AS7315-30X 4 x 1G, 16 x 10G, 8 x 25G, 2 x 100G ports with Qumran AX. Open cell site gateway platform for mobile backhaul networks

    300G CELL SITE ROUTER AS7315-30X 4 x 1G, 16 x 10G, 8 x 25G, 2 x 100G ports with Qumran AX. Open cell site gateway platform for mobile backhaul networks

  • 64G CELL SITE ROUTER AS5915-18X 6 x 1G/10G, 8 x 1G, 4 x 1G copper switch ports with Qumran UX. Open design cell site gateway for mobile backhaul networks

    64G CELL SITE ROUTER AS5915-18X 6 x 1G/10G, 8 x 1G, 4 x 1G copper switch ports with Qumran UX. Open design cell site gateway for mobile backhaul networks

Comparison

Product Name Switch Silicon Port Interface Switching Capacity Forwarding Rate Packet Buffer Size Operation Temperature Airflow
CSR200 Qumran-UX 4 X 1G RJ45
8 X 1G SFP
6x 10G SFP+
64Gbps 125Mpps Deep Buffering 8Gb DRAM-Based -40°C~70°C Left-to-Right
CSR300 Qumran-AX 4 X 1G RJ45
16 x 10G SFP+
8 X 25G SFP28
2X 100G QSFP28
300Gbps 300Mpps Deep Buffering 24Gb DRAM-Based -40°C~65°C Left-to-Right
Right-to-Left
CSR310 Qumran-AX 20 X 10G SFP+
4 X 25G SFP28
3 x 100G QSFP28
300Gbps 300Mpps Deep Buffering 24Gb DRAM-Based -40°C~65°C Left-to-Right
Right-to-Left
CSR320 Qumran-AX 16 X 10G SFP+
8 X 25G SFP28
2 X 100G QSFP28
300Gbps 300Mpps Deep Buffering 24Gb DRAM-Based -40°C~65°C Front-to-Back
CSR440 Qumran 2A 24 X 25G SFP28
2 X 100G QSFP28
2 X 400G QSFP-DD
800Gbps 600 Mpps External GDDR6 2GBytes -40°C~65°C Front-to-Back
