ET7302-AOC-xM
25 Gbps Active Optical Cable
The ET7302-AOC-xM is a 3~100 m active optical cable with one SFP28 to one SFP28 25G connectors. The active optical cables are 25G hot-pluggable cables that support Infiniband and Ethernet data transmission. The cables provide parallel interconnects—4 transmitting and 4 receiving data lanes—and support distances up to 100 meters.
.png)
Overview
The ET7302-AOC-xM is a 3~100 m active optical cable with one SFP28 to one SFP28 25G connectors. The active optical cables are 25G hot-pluggable cables that support Infiniband and Ethernet data transmission. The cables provide parallel interconnects—4 transmitting and 4 receiving data lanes—and support distances up to 100 meters. The active optical cables are composed of multi-channel optical transceivers at both ends and multimode fiber cable in between. This integrated optical module solution removes the complicated optical fiber interface and replaces it with a friendly and intuitive electrical-to-electrical interface. The ET7302-AOC-xM is designed to meet the requirements of high-speed, high-density, and low-power-consumption applications in today's data centers.
Specs
Features
- Hot pluggable
- Bit rate support from 25G to 28GB/s
- Pre-terminated fiber cable
- Operating environment temperature: 0℃ ~ 70℃
- Maximum power consumption 1.0 W each terminal
- SFP28 housing with enhanced EMI shielding
- Single 3.3 V power supply
- Programmable EEPROM for serial identification
- Up to 70 m/100 m by active optical cable with OM3/OM4 fiber
- SFF-8472
- SFF-8432 Mechanical MSA
- RoHS complaint
Downloads
| Category | File Name | Version | Release Date | File Size | Download |
|---|---|---|---|---|---|
| Datasheet | ET7302-AOC DS R02 | US | 2021-12-02 | 1063.62 KB | Download |
