ET4202-RJ45

1000BASE-T Copper SFP Transceiver

The 1000BASE-T copper SFP transceiver is a high-performance, cost-effective module, compliant with Gigabit Ethernet and 1000BASE-T standards, as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supports 1000Mb/s data rate up to 100 meters reach over twisted-pair Category 5 cable.

Overview

The 1000BASE-T copper SFP transceiver is a high-performance, cost-effective module, compliant with Gigabit Ethernet and 1000BASE-T standards, as specified in IEEE 802. 3-2002 and IEEE 802.3ab, which supports 1000Mb/s data rate up to 100 meters reach over twisted-pair Category 5 cable.

Specs

Features

  • Hot-pluggable SFP footprint
  • Low power dissipation
  • Compact RJ-45 connector assembly
  • Detailed product information in EEPROM
  • +3.3V single power supply
  • 1000 BASE-T operation in host systems with SGMII interface
  • Compliant with SFP MSA
  • Compliant with IEEE Std 802.3™-2002
  • Commercial: 0°C to +70°C

Downloads

Category File Name Version Release Date File Size Download
Datasheet ET4202-RJ45 DS R01 US 2021-06-04 2405.71 KB Download
