  |  ECS4660-28F

L3 GIGABIT METRO ETHERNET SWITCH

ECS4660-28F

The Edgecore ECS4660-28F is a standalone L3 Gigabit Metro Ethernet routing switch with 24 1000Base-X SFP slots, two 10G XFP uplink slots, and two 10G module slots that can support two additional 10G uplinks.

ECS4660-28F Warranty Support Period: 5 years.

The product has completed the End of Life (EOL) process effective on October 1st, 2018

For more details, please refer to item #8 in the Product Warranty Statement.

Overview

The Edgecore ECS4660-28F is a standalone L3 Gigabit Metro Ethernet routing switch with 24 1000Base-X SFP slots, two 10G XFP uplink slots, and two 10G module slots that can support two additional 10G uplinks. With up 107Mpps performance, the ECS4660-28F is ideal for service provider aggregation deployment, providing wire-speed L2 switching and L3 unicast and multicast routing. To maintain high availability, the ECS4660-28F provides redundant power, a hot swappable fan tray, configuration rollback, and G.8032 ring protection.

Features

  • 24 x 1000 Base-X SFP ports + 2 10G XFP ports
  • Flexible AC/DC Dual Power Source
  • Ethernet Service OAM (802.3ah / 802.1ag / Y.1731)
  • Hot swappable components for field upgrade
  • Front access interfaces for easy management
  • G.8032 Ethernet Ring Protection Switching

Downloads

ECS4660-28F FW_V1.2.2.1

Firmware  21 MB

ECS4660-28F_Management Guide-R03

User Manual  28 MB

ECS4660-28F Installation Guide

User Manual  2 MB

ECS4660-28F_DS

Datasheet  200 KB
