  |  AS5712-54X

10GBE DATA CENTER SWITCH

AS5712-54X

AS5712-54X has 48-Port 10G SFP+ with 6x40G QSFP+ uplinks with ONIE software installer. AS5712-54X embedded Broadcom Trident II 720Gbps and Intel Atom C2538 CPU as well as PHY-Less/Re-timer-Less, dual -48VDC 400W PSUs included and port-to-power airflow.

AS5712-54X Warranty Support Period: 3 years.

The product has completed the End of Life (EOL) process effective on April 1st, 2020.

For more details, please refer to item #8 in the Product Warranty Statement.

Overview

The Edgecore AS5710-54X/AS5712-54X switch meets the high-performance, availability, and network-scaling requirements of enterprise and cloud data centers. The AS5710-54X/AS5712-54X provides full line-rate switching at Layer 2 or Layer 3 across 48 x 10GbE ports and 6 x 40GbE uplinks. The switch can be deployed either as a Top-of-Rack switch, or as part of a 10GbE or 40GbE distributed spine, forming a non-blocking folded CLOS data center fabric. The switch is rack mountable in either a standard 19 inch rack, or with the Open Rack Switch Adapter in the 21 inch Open Rack.

The AS5710-54X/AS5712-54X hardware provides the high availability features required for data center operation, including; redundant, hot-swappable AC or -48 VDC PSUs or 12 VDC power input; fan with 4+1 redundant fan modules; and port-to-power or power-to-port airflow options. The AS5710-54X/AS5712-54X is an ideal Top-of-Rack switch for virtualized data centers, with its support of VXLAN and NVGRE tunneling functions in hardware.

Features

  • Cost-effective, bare-metal switch infrastructure for data center fabric.
  • 48 x SFP+ switch ports, supporting 10GbE (DAC, 10GBASE-SR/LR) or 1GbE (1000BASE-T/SX/LX).
  • 6 x 40 QSFP switch ports, each supporting 40GbE (DAC, 40GBASE-SR4/LR4) or 4 x 10GbE (DAC or fiber breakout cable).
  • Port Grouping to group 4 x 10G ports into one 40G port at the physical layer for maximum bandwidth utilization, and for 300m optical reach over MMF (Subject to NOS options).
  • Full line-rate Layer 2 or Layer 3 forwarding of 1.44 Tbps full duplex.
  • VXLAN and NVGRE tunneling support in hardware for network virtualization.
  • Rack mountable in standard 19″ racks. Mountable in 21″ Open Rack with the Open Rack Switch Adapter.
  • Supports hot/cold aisle with port-to-power and power-to-port airflow SKUs.
  • All ports on front; PSUs, fan modules on rear.
  • Hot-swappable, load sharing, redundant AC or -48 VDC PSUs. 12 VDC power input option.
  • Hot swappable 4+1 redundant fan modules.
  • Management: Ethernet and console RJ-45 ports; USB storage port.
  • Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commerical NOS offerings.
  • Compatible with Big Switch Networks Big Cloud Fabric™ and Big Monitoring Fabirc™

Compatible
Software Option

  • Open Compute Project – Open Network Linux
  • Arrcus – ArcOS

  • Pica8 – PicOS

  • Pluribus Netvisor ONE

Downloads

AS5712-54X Safety and Regulatory Information R06

Safety and Regulatory Information  1 MB

AS5712-54X Quick Start Guide R08

User Manual  2 MB

AS5710_AS5712-54X DS R09

Datasheet  197 KB
