ACCESS ROUTERS
Disaggregated Cell Site Gateways (DCSG) based on an open and disaggregated architecture for existing 2G/3G/4G and future 5G mobile
infrastructures.
DCSG NETWORK TOPOLOGY
400G
100G
DATA CENTER
CORE ROUTER
INTERNET CORE CASSINI
AGGREGATION
ROUTER
CELL SITE
GATEWAY
DCSG
RRU
USER EQUIPMENT MAST NodeB [ BBU [
eNodeB
ACCESS gNodeB BACKHAUL
DISAGGREGATED CELL SITE CSR200 CSR300
4 x 1G RJ45
6 x 1G/10G SFP+
GATEWAYS 8 x 1G SFP 16 x 1G/10G SFP+
4 x 1G RJ45 ports 8 x 1G/10G/25G SFP28
Flexible Port Configuration 1G,10G, 25G, 100G, 400G Broadcom® Qumran-UX 2 x 100G QSFP28 ports
Broadcom® DNX Qumran Compact Design, Lite Model Broadcom® Qumran-AX
Intel® Xeon® Family CPU
IEEE1588v2 with SyncE
Temperature Hardened Design
CSR440
24 x 25G SFP28 CSR310 CSR320
2 x 100G QSFP28 20 x 1G / 10 G SFP+ 16 x 10G SFP+
2 x 400G QSFP-DD ports 4 x 1G / 10G / 25G SFP28 8 x 25G SFP28
Broadcom® Qumran-2A 3 x 100G QSFP28 ports 2 x 100G QSFP28 ports
5G mobile xHaul networks Broadcom® Qumran-AX Broadcom® Qumran-AX
Stackable Model, GNSS Antenna GNSS Antenna
