Page 37 - Edgecore Product Catalogue 2026
P. 37
10GbE SFP+ Ethernet Active Optical Cable and Direct Attach Cable
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET5402-DAC-xM 10GBASE-CU Twinax copper, fixed length n/a n/a
ET5402-AOC-xM 10GBASE-AOC MM fiber, fixed length 850 n/a
Accessories
25GbE Ethernet Active Optical Cable and Direct Attach Cable
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET7302-DAC-xM 25GBASE-CR Twinax copper, fixed length n/a n/a
ET7302-AOC-xM 25GBASE-AOC MM fiber, fixed length 850 n/a
40GbE QSFP+ Ethernet Active Optical Cable and Direct Attach Cable
Transceiver & Cable Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET6402-DAC-xM 40GBASE-CR4 Twinax copper, fixed length n/a n/a
Edgecore’s pluggable modules provide flexible connectivity across the Edgecore networking portfolio. ET6402-10DAC-xM 4× 10GBASE-AOC Twinax copper, fixed length n/a n/a
40GBASE-CR4 to
Supporting fiber and copper media, speeds from 1Gbps to 800Gbps. Available options include SFP, ET6402-AOC-xM 40GBASE-AOC MM fiber, fixed length 850 n/a
SFP+, SFP28, QSFP+, QSFP28, and QSFP-DD transceivers, packet optical transceivers, DAC, and AOC
cables.
100GbE QSFP28 Ethernet Active Optical Cable and Direct Attach Cable
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET7402-DAC-xM 100GBASE-CR4 Twinax copper, fixed length n/a n/a
ET7402-AOC-xM 100GBASE-AOC MM fiber, fixed length 850 n/a
ET7402-25DAC-xM 100GBASE-CR4 to Twinax copper, fixed length n/a n/a
4× 25GBASE-CR
100GBASE-AOC to
ET7402-25AOC-xM 4× 25GBASE-AOC MM fiber, fixed length 850 n/a
400GbE Ethernet Active Optical Cable and Direct Attach Cable
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET7502-DAC-xM 400GBASE-CR8 Twinax copper, fixed length n/a n/a
ET7502-AOC-xM 400GBASE-AOC MM fiber, fixed length 850 n/a
ET7502-B4D-xM 400GBASE-CR8 to Twinax copper, fixed length n/a n/a
4× 100GBASE-CR2
Gigabit Ethernet SFP Transceiver
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET4202-RJ45 1000BASE-T CAT5/100m n/a RJ-45
ET4202-SX 1000BASE-SX 50μ MMF/550m 850 Duplex LC
ET4202-LX 1000BASE-LX SMF/10km 1310 Duplex LC
ET4202-EX 1000BASE-EX SMF/40km 1310 Duplex LC
ET4202-ZX 1000BASE-ZX SMF/80km 1550 Duplex LC
10GbE SFP+ Transceiver
Model name Standard/Type Media/Reach Wavelength (nm) Receptacle
ET5402-RJ45 10GBASE-T CAT6A/30mvv n/a RJ-45
ET5402-SR 10GBASE-SR 50μ MMF/300m 850 Duplex LC
ET5402-LR 10GBASE-LR/LW SMF/10km 1310 Duplex LC
ET5402-ER 10GBASE-ER/EW SMF/40km 1550 Duplex LC
ET5402-ZR 10GBASE-ZR/ZW SMF/80km 1550 Duplex LC
36 37
