Access Point Edge Gateway
The OpenLAN Gateway is a compact edge gateway platform designed to extend the OpenLAN
architecture from WAN to wireless.
Core Capabilities
EAP102 OAP101 OAP105
Intelligent features that optimize every connection.
Wi-Fi 6 4×4:4 Wi-Fi 6 2×2:2 Wi-Fi 7 4×4×4:4
Indoor Dual Radio Outdoor Dual Radio Outdoor Tri-band
Support BLE Support BLE/Zigbee/Thread Support c/Thread
1 × 2.5GbE PoE WAN 1 × 2.5GbE PoE WAN 1 × 10GbE PoE WAN
1 × 2.5GbE LAN 1 x GbE LAN 1 × 10GbE LAN
IP66, IP68 IP66, IP68 Multi-WAN Open Network Application-aware Flexible Port
Resilience Platform Routing Options
Z1
EAP112 2 × 1G BASE-T (or 2 × 1G SFP) WAN
Wi-Fi 6 2×2:2 4 × 1G BASE-T LAN
Indoor Dual Radio 1 x RJ-45 Console
Wi-Fi HaLow/LTE 2 x USB 3.0 port
Support BLE/Zigbee/Thread
1 x GbE PoE WAN
1 x GbE LAN
IP65
Branch-to-Cloud Architecture
From gateway to access, built for unified OpenLAN management.
Wi-Fi HALOW
CloudSDK
Controller
Enterprise A Enterprise B
Wi-Fi HaLow Camera Wi-Fi HaLow Dongle Portable IoT Gateway
VPN Tunnel
Wi-Fi HaLow Wi-Fi HaLow Wi-Fi HaLow Edge Gateway Edge Gateway
150° Wide-angle Lens USB 2.0 type C Wi-Fi 2.4GHz
20m IR Distance AP/Station/Mesh Mode BLE/Zigbee
SONY CMOS Sensor Battery Operated
IP66 OLS Switch OLS Switch
OpenWiFi AP OpenWiFi AP
