Intel® Gaudi® Accelerator Scale-out for GenAl Requirements:One Node Definition

node
QSFP-DD QSFP-DD QSFP-DD QSFP-DD QSFP-DD QSFP-DD

Retimer Retimer Retimer

Intel® Gaudi® Accelerator Scale-out for GenAl Requirements:One Cluster Definition
(32 Nodes with 256 GPU)

Leaf Leaf Leaf
Switch Switch Switch 3x Leaf Switch
64 port 800 GbE

96x QSFP
400GbE

... 256x OAM

node 01 node 02 node 03 node 04 node 05 node 06 node 32

Intel® Gaudi® Accelerator Scale-out for GenAl Requirements:Maximum-scale Cluster Definition
(1024 Nodes with 8192 GPU)

16x Blue Spine Switches 16x Purple Spine Switches 16x Yellow Spine Switches
48 x Spine
Switches
64 port 800 GbE

2 x 800 GbE
for each connection

96x
Leaf Switches
... 1024x nodes

8192x Accelerators

Cluster 01 Cluster 02 Cluster 03 Cluster 04 Cluster 05 Cluster 06 Cluster 32
