ECS4210-12T features 12 ports; with 8 x GE + 4 GE SFP ports, is a high-performance Gigabit Ethernet Layer 2 switch with fan-less design.

The EWS5207 is an enterprise-grade wireless LAN controller that provides establishments such as hotels, universities, or even complete municipalities with a comprehensive set of managed Wi-Fi features at a competitive license-free price point.

ECS4510-28F is a high-performance Gigabit Ethernet switch featuring 28 ports; with 22 x GE SFP + 2 x GE Combo (RJ45/SFP) + 2 x 10G SFP+ ports + 1 x expansion slot . ECS4510-28F is a Layer 2+ managed switch with 128 Gbps switching capacity, has with 1 x RJ45 console port, 1 x USB type A storage port, RPU connector and Stack up to 4 units.

The Edgecore Wedge100BF-65X switch is a Top-of-Rack (TOR) or spine switch for high-performance data centers. In a 2RU form factor, the switch provides line-rate L2 and L3 switching across the 65 x QSFP28 ports, supporting up to 65 x 25/40/50/100 GbE connections.

ECS4510-52P is a high-performance Gigabit Ethernet switch featuring 52 ports; with 48 x GE PoE+ and 2 10G SFP+ ports, and one 10G dual port expansion slot. ECS4510-52P is a Layer 2+ managed switch with 176 Gbps switching capacity, has with 1 x RJ45 console port, 1 x USB type A storage port, RPU connector and Stack up to 4 units. The PoE Budget is max. 780W

ECS4110-28P features 28 ports; with 24 x GE PoE+ and 4 GE SFP ports, is a high-performance Gigabit Ethernet L2 access switches with 56 Gbps switching capacity. The PoE Budget is max. 390W.

ECS2100-28P is a Web Smart Pro Switch, it supports 24 x GE PoE+ ports and 4 GE SFP ports . The PoE Budget is max.200W.

AS6712-32X is a 32-Port 40G QSFP+ switch with ONIE software installer. AS6712-32X embedded Broadcom Trident II 1.28Tbps and Intel Atom C2538 CPU as well as dual 110-230VAC 400W PSUs included and port-to-power airflow. AS6712-32X is 3-year Hardware Warranty.

Edgecore ECS4120-28F-I switch is an enhanced temperature Gigabit Ethernet access switch with four 10G uplink ports.

AS4610-54T has 48-Port GE RJ45 port + 4x10G SFP+ and 2 port QSFP+ by DAC or 20G QSFP+ Transceiver. AS4610-54T embedded Broadcom Helix 4 and Dual-core ARM Cortex A9 1GHz with dual 110-230VAC 150W hot-swappable PSUs and PSUs with port-to-power airflow. AS4610-54T is 3-year Hardware Warranty.

The Edgecore AS7512-32X provides line-rate L2 and L3 switching across to 32 x QSFP28 ports, supporting up to 32 x 40/100 GbE, 64 x 50 GbE, or 128 x 10/25 GbE connections.

ECS4810-12M is a carrier grade aggregation and access switch consists of 12 Combo Gigabit Ethernet ports. With 1 out of band 1000Mbps RJ45 Management Port + 1 DB15 alarm port. ECS4810-12M provides dual power input with AC and DC and the operating temperature is ranging from -250C to 650C, the Fan-less design ensures noiseless operation and increase the reliability of the system.

The Edgecore ECS4660-28F is a standalone L3 Gigabit Metro Ethernet routing switch with 24 1000Base-X SFP slots, two 10G XFP uplink slots, and two 10G module slots that can support two additional 10G uplinks

The Wedge 100-32X switch provides 32 QSFP28 ports that can each run at 100GbE/40GbE, or as 4 x 25 GbE/4 x 10 GbE/2 x 50 GbE through breakout cables.

ECS2100-52T is a Web Smart Pro Switch, it supports 48 x GE ports + 4 x integrated Gigabit SFP ports. Besides providing more uplink bandwidth, the SFP ports can be used for redundant links.

ECS2110-26T is a Web Smart Pro Switch, it supports 24 x GE ports + 2 x 10G SFP+ ports for 10G switch or server connectivity.

The Edgecore ECS4100-26TX-ME switch is a Gigabit Ethernet access switch with two 10G uplink ports. The switch is ideal for Internet Service Providers (ISPs) and Multiple System Operators (MSOs) to provide home users with triple-play services with up to Gigabit bandwidth.

The AS5812-54T is an ideal Top-of-Rack switch which provides full line-rate switching at Layer 2 or Layer 3 across 48 x 10GbE ports and 6 x 40GbE uplinks. AS5812-54T has 48 x RJ-45 Copper, supporting 10GBASE-T, 1000BASE-T and 100BASE-TX Ethernet on Cat 6, Cat 6 A and Cat 7 twisted-pair cable.

AS5712-54X has 48-Port 10G SFP+ with 6x40G QSFP+ uplinks with ONIE software installer. AS5712-54X embedded Broadcom Trident II 720Gbps and Intel Atom C2538 CPU as well as PHY-Less/Re-timer-Less, dual -48VDC 400W PSUs included and port-to-power airflow. AS5712-54X is 3-year Hardware Warranty.

ECS4620-28T is a compact but high-performance Gigabit Ethernet Layer 3 switch featuring 28 ports; with 24 10/100/1000Base-T ports, 2 10G SFP+ ports, and one 10G dual port expansion slot. ECS4620-28T has with 1 x RJ45 console port, 1 x USB type A storage port and RPU connector with fan-less design and Stack up to 4 units.

AS7712-32X is a 32-Port 100G QSFP28 switch with ONIE software installer. AS7712-32X embedded Broadcom Tomahawk 3.2Tbps and Intel Atom C2538 CPU as well as dual 110-230VAC 650W PSUs included and power-to-port airflow. AS7712-32X has 3-year Hardware Warranty.
